Motorized Awning Sizes and Projection Guide

Understanding Awning Width

Awning width is the span across the opening and along the mounting line. Record the clear wall width, then note trim, fixtures and adjacent walls that could affect the cassette or arms.

What Projection Means

Projection describes how far the awning extends outward from the mounting line. The shaded area also depends on mounting height, arm angle and the position of the sun, so nominal projection is a planning dimension rather than a promise of exact shade coverage.

Width Versus Projection

A wider awning does not automatically mean a greater projection. Available width-to-projection combinations depend on the selected model and its engineering configuration. Always read the model-specific source table as matched width and projection pairs.

Measure the Installation Area

Prepare the following information before requesting a quotation. Measurements should be taken at the actual mounting area and checked against the building conditions visible in your photos or drawings.

• Available Wall Width

  Measure the clear span where the cassette could be fixed.

• Desired Projection

  Record the intended shade depth from the mounting line.

• Mounting Height

  Note the height above openings and the space needed when retracted.

• Window and Door Clearance

  Check opening paths, handles and trim for interference.

• Nearby Obstacles

  Record lights, vents, gutters, corners, railings and other projections.

• Mounting Surface

  Identify the wall or fascia; the final fixing approach needs site review.

• Installation Photos

  Include straight-on and side views to show the surrounding conditions.

Sizing Patios and Commercial Spaces

Residential and commercial projects use the same width and projection principles, but the planning questions are different. Review the intended use, mounting context and quantity before selecting a model.

How to Read a Product Size Table

Read width and projection as a matched row and column in the selected product documentation. For our featured full cassette awning, send your dimensions for quotation; a complete size matrix has not yet been confirmed.

Start with the product source for the model you are considering. The Full cassette product details explain the configuration information to submit for a quotation. Each product requires its own compatible size confirmation.

Common Measurement Mistakes

A careful site check helps prevent an apparently suitable size from becoming difficult to install or use.

1. 01Ignoring Obstructions: Check fixtures, gutters, lights, rails and corners before selecting a width.
2. 02Confusing Width with Projection: Width runs along the wall; projection extends outward from it.
3. 03Overlooking Mounting Height: Height affects clearance, appearance and the usable shade area.
4. 04Assuming Every Size Combination Is Available: Use the exact model table; maximum values cannot be freely paired.
5. 05Not Checking the Mounting Surface: The wall or fascia and its fixing conditions must be reviewed for the actual building.

Custom Sizing Questions

For a useful quotation, send the project information below. The final installation size and fixing approach must be confirmed against the real building conditions.

• Product Model
• Installation Location
• Opening Width
• Desired Projection
• Quantity
• Fabric Preference
• Photos or Drawings
